Fluke Calibration 2700G Series Reference Pressure Gauge

Fluke Calibration · Model 2700G · Pressure Measurement

The 2700G Series are high-accuracy digital reference pressure gauges accurate to 0.02 % of full scale, used as a calibration reference standard or wherever precise pressure measurement is required. Nine models cover vacuum and positive pressure and connect tool-free to the P5500-series comparison test pumps.

Key specifications

• Ranges from -15 to 15 psi (-100 to 100 kPa) up to 0 to 10,000 psi (0 to 70 MPa); nine models
• Measurement uncertainty to 0.02 % of full scale (0.05 % FS on vacuum)
• Uncertainty includes linearity, hysteresis, repeatability, resolution, 1-year stability and 18-28 C temperature effects
• Media: clean dry non-corrosive gas; mid/high ranges support liquids/gases compatible with 316 stainless steel
• 5.5-digit display with 20-segment bar graph; 21 engineering units plus 1 custom; 1/4 in NPT male connection
• Battery powered (3x AA, ~75 h life); tare, damping, auto-off and supervisor function lock

Download the 2700G datasheet (PDF)

Request a quote from Controware — your authorized Fluke Calibration distributor in the UAE, KSA and Egypt — buy or rent with genuine stock, calibration and technical support.
