Megger FRAX101 Sweep Frequency Response Analyzer

Megger · Model FRAX101 · Electrical Test Instruments

Sweep frequency response analyzer (SFRA) detecting winding deformation and core movement in power transformers by comparison against a reference.

Key specifications

• Test frequency range: 0.1 Hz to 25 MHz
• Output voltage: adjustable, default 10 V
• Test points per sweep: 1046 default (up to 32,000)
• Measurement time: ~64 s (37 s fast mode)
• Standards: IEC 60076-18, IEEE C57.149

Download the FRAX101 datasheet (PDF)

Request a quote from Controware — your authorized Megger distributor in the UAE, KSA and Egypt — buy or rent with genuine stock, calibration and technical support.
